BSP Type Elements

BTH 1.25 Inch CMO

Item Code : N-340=N-341

Flange/Cup Details : 1.25"/32mm
BTH 1.25 Inch CMO TSP 7 Inch

Item Code : N-342

Flange/Cup Details : 1.25"/32mm
BSP 1.25 Inch CMO Type Small 6 Inch

Item Code : N-343=N-344=N-345

Flange/Cup Details : Socket 1.25"
BTH1.25 Inch II ROD Plain

Item Code : N-350=N-351=N-352=N-353=N-354

Flange/Cup Details : 1.25"/32mm
BTH 1.25 Inch II Rod with TSP

Item Code : N-358=N-359=N-360=N-361=N-362

Flange/Cup Details : 1.25"/32mm
BTH 1.25 Inch III Rod

Item Code : N-365=N-366

Flange/Cup Details : 1.25"/32mm
BTH 1.5 Inch II ROD Height 10 Inch

Item Code : N-370=N-371

Flange/Cup Details : Socket 1.25"/32mm
BTH 1.5 Inch II Rod with TSP

Item Code : N-372=N-373=N-374=N-375

Flange/Cup Details : 1.5"/38mm
BTH 1.5 Inch III ROD PLAIN

Item Code : N-380=N-381=N-382=N-383=N-384

Flange/Cup Details : 1.5"/38mm
BTH 1.5 Inch III Rod with TSP

Item Code : N-390=N-391=N-392=N-393=N-394

Flange/Cup Details : 1.5"/38mm
BTH 2 III Inch ROD 12 PLAIN

Item Code : N-401=N-402=N-403

Flange/Cup Details : 2"/51mm
BTH 2 Inch III ROD 13 Inch PLAIN CMO TYPE

Item Code : N-404

Flange/Cup Details : 2"/51mm
BTH 2 III ROD 12 TSP 11

Item Code : N-410=N-411=412

Flange/Cup Details : 2"/51mm
BTH 2 III ROD 13 TSP 11 CMO TYPE

Item Code : N-413

Flange/Cup Details : 2"/51mm
BTH 1.25 Inch CMO

Item Code : N-340 / N-341

Flange/Cup Details : Socket 1.25"/32mm
No of TSP and Dia(mm) : 1 TSP Dia. 9.5mm
Code Depth Rating
N-340 19.5"/241mm 1.5KW 230V 50 Hz AC
N-341 19.5"/241mm 3kW 230V 50 Hz AC
BTH 1.25 Inch CMO TSP 7 Inch

Item Code : N-342

Flange/Cup Details : 1.25"/32mm
No of TSP and Dia(mm) : 1 TSP 9.5mm
TSP Length : 7"/178mm
Code Depth Rating
N-340 19.5"/241mm 1.5KW 230V 50 Hz AC
N-342 9.5"/241mm 2kW 230V 50 Hz AC
BSP 1.25 Inch CMO Type Small 6 Inch

Item Code : N-343 / N-344 / N-345

Flange/Cup Details : Socket 1.25"
Code Depth Rating
N-343 6"/152mm 1KW 230V 50 Hz AC
N-344 6"/152mm 1.5kW 230V 50 Hz AC
N-345 6"/152mm 2kW 230V 50 Hz AC
BTH1.25 Inch II ROD Plain

Item Code : N-350 / N-351 / N-352 / N-353 / N-354

Flange/Cup Details : 1.25"/32mm
Code Depth Rating
N-350 7"/178mm 2KW 230V 50 Hz AC
N-351 10"/255mm 2kW 230V 50 Hz AC
N-352 10"/255mm 3kW 230V 50 Hz AC
N-353 11"/280mm 2kW 230V 50 Hz AC
N-354 11"/280mm 3kW 230V 50 Hz AC
BTH 1.25 Inch II Rod with TSP

Item Code : N-358 / N-359 / N-360 / N-361 / N-362

Flange/Cup Details : 1.25"/32mm
Code Depth Rating
N-358 7"/178mm 2KW 230V 50 Hz AC
N-359 10"/255mm 2kW 230V 50 Hz AC
N-360 10"/255mm 3kW 230V 50 Hz AC
N-361 11"/280mm 2kW 230V 50 Hz AC
N-362 11"/280mm 3kW 230V 50 Hz AC
BTH 1.25 Inch III Rod

Item Code : N-365 / N-366

Flange/Cup Details : 1.25"/32mm
Code Depth Rating
N-365 7"/178mm 3KW 230V 50 Hz AC
N-366 10"/255mm 3kW 230V 50 Hz AC
BTH 1.5 Inch II ROD Height 10 Inch

Item Code : N-370 / N-371

Code Depth Rating
N-370 10"/255mm 2KW 230V 50 Hz AC
N-371 10"/255mm 3kW 230V 50 Hz AC
BTH 1.5 Inch II Rod with TSP

Item Code : N-372 / N-373 / N-374 / N-375

Flange/Cup Details : 1.5"/38mm
Code Depth TSP Length Rating
N-372 10"/255mm 7"/178mm 2KW 230V 50 Hz AC
N-373 10"/255mm 7"/178mm 3kW 230V 50 Hz AC
N-374 11"/280mm 11"/280mm 2kW 230V 50 Hz AC
N-375 11"/280mm 11"/280mm 3kW 230V 50 Hz AC
BTH 1.5 Inch III ROD PLAIN

Item Code : N-380 / N-381 / N-382 / N-383 / N-384

Flange/Cup Details : 1.5"/38mm
Code Depth Rating
N-380 7”/178mm 3KW 230V 50 Hz AC
N-381 10"/255mm 2kW 230V 50 Hz AC
N-382 10"/255mm 3kW 230V 50 Hz AC
N-383 11"/280mm 2kW 230V 50 Hz AC
N-384 11"/280mm 3kW 230V 50 Hz AC
BTH 1.5 Inch III Rod with TSP

Item Code : N-390 / N-391 / N-392 / N-393 / N-394

Flange/Cup Details : 1.5"/38mm
Code Depth TSP Length Rating
N-390 7”/178mm 7"/178mm 3KW 230V 50 Hz AC
N-391 10"/255mm 7"/178mm 3kW 230V 50 Hz AC
N-392 10"/255mm 11"/280mm 3kW 230V 50 Hz AC
N-393 11"/280mm 11"/280mm 4.5kW 230V 50 Hz AC
N-394 11"/280mm 11"/280mm 6kW 230V 50 Hz AC
BTH 2 III Inch ROD 12 PLAIN

Item Code : N-401 / N-402 / N-403

Flange/Cup Details : 2"/51mm
Code Depth Rating
N-401 10"/255mm 3KW 230V 50 Hz AC
N-402 12"/305mm 5kW 230V 50 Hz AC
N-403 12"/305mm 6kW 230V 50 Hz AC
BTH 2 III Inch ROD 12 PLAIN

Item Code : N-404

Flange/Cup Details : 2"/51mm
Code Depth Rating
N-404 13"/330mm 9KW 230V 50 Hz AC
BTH 2 III Inch ROD 12 PLAIN

Item Code : N-410 / N-411 / N-412

Flange/Cup Details : 2"/51mm
No of TSP and Dia(mm) : 1 TSP Dia. 9.5mm
Code Depth TSP Length Rating
N-410 10"/255mm 7”/178mm 3KW 230V 50 Hz AC
N-411 12"/305mm 11"/280mm 5kW 230V 50 Hz AC
N-412 12"/305mm 11"/280mm 6kW 230V 50 Hz AC
BTH 2 III ROD 13 TSP 11 CMO TYPE

Item Code : N-413

Flange/Cup Details : 2"/51mm
No of TSP and Dia(mm) : 1 TSP Dia. 9.5mm
Code Depth TSP Length Rating
N-410 13"/330mm 11”/280mm 9KW 230V 50 Hz AC
