Round Cup 65 mm Dia Elements

Straight Element 10" with 1 TSP of Dia 12.5mm

Item Code : N-180

Flange/Cup Details : 65mm Dia Round Cup
Straight Element 8" with 1 TSP of Dia 12.5mm

Item Code : N-181

Flange/Cup Details :65mm Dia Round Cup
Double U big and Small 9.5" with 1 TSP of Dia 12.5mm

Item Code : N-182

Flange/Cup Details : 65mm Round Cup
Bend type Element with 2 TSP of dia 8mm

Item Code : N-183

Flange/Cup Details : 65mm Round Cup
U long Curve bend & U Element with 1 TSP of 8mm

Item Code : N-184

Flange/Cup Details : 65mm Dia Round Cup
Parallel Double U bend with 2 TSp of 8mm

Item Code : N-185

Flange/Cup Details : 9.5"/241mm
Bend Type Element & U Element with 1 TSP of 8mm

Item Code : N-186

Flange/Cup Details : 65mm Dia Round Cup
Straight Element 10" with 1 TSP of Dia 12.5mm

Item Code : N-180

Flange/Cup Details : 65mm Dia Round Cup
No of TSP and Dia(mm) : 1 TSP Dia 12.5mm
TSP Length : 12"/305mm
Code Depth Rating
N-180 10"/255mm 2KW 230V 50 Hz AC
Straight Element 8" with 1 TSP of Dia 12.5mm

Item Code : N-181

Flange/Cup Details :65mm Dia Round Cup
No of TSP and Dia(mm) : 1 TSP Dia 12.5mm
TSP Length : 10" / 255mm
Code Depth Rating
N-181 8"/203mm 2KW 230V 50 Hz AC
Double U big and Small 9.5" with 1 TSP of Dia 12.5mm

Item Code : N-182

Flange/Cup Details : 65mm Round Cup
No of TSP and Dia(mm) : 1 TSP Dia 12.5mm
TSP Length : 10" / 255mm
Code Depth Rating
N-182 9.5"/241mm 2KW 230V 50 Hz AC
Bend type Element with 2 TSP of dia 8mm

Item Code : N-183

Flange/Cup Details : 65mm Round Cup
No of TSP and Dia(mm) : 2 TSP Dia (8mm + 8mm)
TSP Length : 7"/178mm
Code Depth Rating
N-183 8"/203mm 2KW 230V 50 Hz AC
U long Curve bend & U Element with 1 TSP of 8mm

Item Code : N-184

Flange/Cup Details : 65mm Dia Round Cup
No of TSP and Dia(mm) : 1 TSP Dia 8mm
TSP Length : 8" / 203mm
Code Depth Rating
N-184 9.5"/241mm 2KW 230V 50 Hz AC
Parallel Double U bend with 2 TSp of 8mm

Item Code : N-185

Flange/Cup Details : 9.5"/241mm
No of TSP and Dia(mm) : 2 TSP ( 8mm + 8mm )
TSP Length : 6"/152mm
Code Depth Rating
N-185 9.5"/241mm 2KW 230V 50 Hz AC
Bend Type Element & U Element with 1 TSP of 8mm

Item Code : N-186

Flange/Cup Details : 65mm Dia Round Cup
No of TSP and Dia(mm) : 1 TSP Dia 8mm
TSP Length : 8"/203mm
Code Depth Rating
N-186 8.5"/216mm 2KW 230V 50 Hz AC
