Round Cup 90 mm Dia Elements

Dual Element (J+U) & 2 TSP 8mm

Item Code : N-210

Flange/Cup Details : 90mm Round Cup
Dual Midget Element & 2 TSP 8mm

Item Code : N-211

Flange/Cup Details : 90mm Round Cup
Dual bend Element & 2 TSP 8mm

Item Code : N-212

Flange/Cup Details : 90mm Round Cup
Dual Straight Ele (J+U) 8" 2 TSP 8mm

Item Code : N-213

Flange/Cup Details : 90mm Round Cup
Straight Ele 10" & 1 TSP 8mm+ 1 KSD clamp +1 nozzle

Item Code : N-214

Flange/Cup Details : 90mm Round Cup
Bend Type Element with 1 TSP 8mm +1 KSD clamp big

Item Code : N-215

Flange/Cup Details : 90mm Round Cup
Midget Element with 2 TSP 8mm

Item Code : N-216=N-217

Flange/Cup Details : 90mm Round Cup
Straight Element 10" with 1 TSP 8mm+ KSD clamp Big

Item Code : N-218

Flange/Cup Details : 90mm Cup
Curve Wave Element 10.5" with 1 TSP 8mm and KSD clamp Big

Item Code : N-219

Flange/Cup Details : 90mm Round Cup
Straight Element 10" with 1 TSP 8mm + KSD clamp Big & Male tab Terminal

Item Code : N-220

Flange/Cup Details : 90mm Round Cup
Bend Type Element 9.5" with 2 TSP 9.5mm

Item Code : N-221

Flange/Cup Details : 90mm Round Cup
Bend Type Element 7" Element with 2 TSP 9.5mm & male Terminal

Item Code : N-222

Flange/Cup Details : 90mm Round Cup
Hztl bend type 4" Depth with 1 TSP 9.5mm & 1 KSD clamp Big

Item Code : N-223

Flange/Cup Details : 90mm Round Cup
Dual Straight U big /small with 2 TSP 8mm

Item Code : N-224

Flange/Cup Details : 90mm Round Cup
90mm Round cup L Bend Type with 1 TSP 12mm

Item Code : N-225

Flange/Cup Details : 90mm Round Cup
Straight Element 10" with 2 TSP 8/9.5mm

Item Code : N-226

Flange/Cup Details : 90mm Round Cup
Midget Element 6" with 2 TSP 8mm

Item Code : N-227

Flange/Cup Details : 90mm Round Cup
Midget Element 6" with 2 TSP 8/9.5mm

Item Code : N-228

Flange/Cup Details : 90mm Round Cup
Midget Element 6" with 2 TSP 9.5mm

Item Code : N-229

Flange/Cup Details : 90mm Round Cup
Straight Element 10" with 2 TSP 9.5mm

Item Code : N-230

Flange/Cup Details : 90mm Round Cup
Straight Element 10" with 2 TSP 8mm

Item Code : N-231

Flange/Cup Details : 90mm Round Cup
Midget Ele 6" With 1 TSP 9.5mm +1 Nozzle for fusible plug +1KSD clamp

Item Code : N-232

Flange/Cup Details : 90mm Round Cup
Straight Element 9" with 1 TSP dia 12.5mm

Item Code : N-233

Flange/Cup Details : 90mm Round Cup
Flower Type cup straight Element 10" with 2 TSP 9.5mm

Item Code : N-234

Flange/Cup Details : 90mm Round Cup
Dual Element (J+U) & 2 TSP 8mm

Item Code : N-210

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 TSP ( 8mm + 8mm )
TSP Length : 8"/203mm
Code Depth Rating
N-210 8"/203mm 2KW 230V 50 Hz AC
Dual Midget Element & 2 TSP 8mm

Item Code : N-211

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 TSP ( 8mm + 8mm )
TSP Length : 8"/203mm
Code Depth Rating
N-211 6"/165mm 2KW 230V 50 Hz AC
Dual Midget Element & 2 TSP 8mm

Item Code : N-211

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 TSP ( 8mm + 8mm )
TSP Length : 8"/203mm
Code Depth Rating
N-211 6"/165mm 2KW 230V 50 Hz AC
Dual bend Element & 2 TSP 8mm

Item Code : N-212

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 TSP ( 8mm + 8mm )
TSP Length : 7"/178mm
Code Depth Rating
N-212 6"/165mm 2KW 230V 50 Hz AC
Straight Ele 10" & 1 TSP 8mm+ 1 KSD clamp +1 nozzle

Item Code : N-214

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 1 TSP 8mm
TSP Length : 11"/280mm
Code Depth Rating
N-214 10"/255mm 2KW 230V 50 Hz AC
Bend Type Element with 1 TSP 8mm +1 KSD clamp big

Item Code : N-215

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 1 TSP 8mm
TSP Length : 7"/178mm
Code Depth Rating
N-215 6.5"/165mm 2KW 230V 50 Hz AC
Midget Element with 2 TSP 8mm

Item Code : N-216 / N-217

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 TSP ( 8mm + 8mm ), (8mm + 9.5mm)
Code Depth TSP Length Rating
N-216 6"/152mm 8”/203mm, 8”/203mm 2KW 230V 50 Hz AC
N-217 6"/152mm 7”/178mm, 11”/280mm 2kW 230V 50 Hz AC
Straight Element 10" with 1 TSP 8mm+ KSD clamp Big

Item Code : N-218

Flange/Cup Details : 90mm Cup
No of TSP and Dia(mm) : 1 TSP 8mm
TSP Length : 11"/280mm
Code Depth Rating
N-218 10"/255mm 2KW 230V 50 Hz AC
Curve Wave Element 10.5" with 1 TSP 8mm and KSD clamp Big

Item Code : N-219

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 1 TSP 8mm
TSP Length : 7"/178mm
Code Depth Rating
N-219 10.5"/265mm 2KW 230V 50 Hz AC
Straight Element 10" with 1 TSP 8mm + KSD clamp Big & Male tab Terminal

Item Code : N-220

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 1 TSP 8mm
TSP Length : 11"/280mm
Code Depth Rating
N-220 10"/255mm 2KW 230V 50 Hz AC
Bend Type Element 9.5" with 2 TSP 9.5mm

Item Code : N-221

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 TSP 9.5mm + 9.5mm
TSP Length : 11"/280mm
Code Depth Rating
N-221 9.5"/241mm 2KW 230V 50 Hz AC
Bend Type Element 7" Element with 2 TSP 9.5mm & male Terminal

Item Code : N-222

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 TSP 9.5mm + 9.5mm
TSP Length : 7"/178mm
Code Depth Rating
N-222 9.5"/241mm 2KW 230V 50 Hz AC
Hztl bend type 4" Depth with 1 TSP 9.5mm & 1 KSD clamp Big

Item Code : N-223

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 1 TSP 9.5mm
TSP Length : 4"/102mm
Code Depth Rating
N-223 4"/102mm 2KW 230V 50 Hz AC
Dual Straight U big /small with 2 TSP 8mm

Item Code : N-224

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 ( 8mm+8mm)
TSP Length : 11"/280mm
Code Depth Rating
N-224 11"/280mm 2KW 230V 50 Hz AC
90mm Round cup L Bend Type with 1 TSP 12mm

Item Code : N-225

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 1 TSP 12mm
TSP Length : 7"/178mm
Code Depth Rating
N-225 7"/178mm 2KW 230V 50 Hz AC
90mm Round cup L Bend Type with 1 TSP 12mm

Item Code : N-225

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 1 TSP 12mm
TSP Length : 7"/178mm
Code Depth Rating
N-225 7"/178mm 2KW 230V 50 Hz AC
Straight Element 10" with 2 TSP 8/9.5mm

Item Code : N-226

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 ( 8mm+9.5mm)
TSP Length : 11"/280mm
Code Depth Rating
N-226 10"/255mm 2KW 230V 50 Hz AC
Midget Element 6" with 2 TSP 8mm

Item Code : N-227

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 ( 8mm+8mm)
TSP Length : 7"/178mm
Code Depth Rating
N-227 6"/152mm 2KW 230V 50 Hz AC
Midget Element 6" with 2 TSP 8/9.5mm

Item Code : N-228

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 ( 8mm+9.5mm)
TSP Length : 7"/178mm
Code Depth Rating
N-228 6"/152mm 2KW 230V 50 Hz AC
Midget Element 6" with 2 TSP 9.5mm

Item Code : N-229

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 ( 9.5mm+9.5mm)
TSP Length : 7"/178mm
Code Depth Rating
N-229 6"/152mm 2KW 230V 50 Hz AC
Straight Element 10" with 2 TSP 9.5mm

Item Code : N-230

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 ( 9.5mm+9.5mm)
TSP Length : 11"/280mm
Code Depth Rating
N-230 10"/ 255mm 2KW 230V 50 Hz AC
Straight Element 10" with 2 TSP 8mm

Item Code : N-231

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 TSP ( 8mm+8mm)
TSP Length : 11"/280mm
Code Depth Rating
N-231 10"/255mm 2KW 230V 50 Hz AC
Midget Ele 6" With 1 TSP 9.5mm +1 Nozzle for fusible plug +1KSD clamp

Item Code : N-232

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 1 TSP Dia. 9.5"
TSP Length : 11"/280mm
Code Depth Rating
N-232 7"/178mm 2KW 230V 50 Hz AC
Straight Element 9" with 1 TSP dia 12.5mm

Item Code : N-233

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 1 TSP Dia.12mm
TSP Length : 9.5"/241mm
Code Depth Rating
N-233 9"/228mm 2KW 230V 50 Hz AC
Flower Type cup straight Element 10" with 2 TSP 9.5mm

Item Code : N-234

Flange/Cup Details : 90mm Round Cup
No of TSP and Dia(mm) : 2 TSP ( 9.5mm + 9.5mm )
TSP Length : 11"/280mm
Code Depth Rating
N-234 10"/256mm 2KW 230V 50 Hz AC
